DYMAX BW AX-550
5” x 5” curing area
High intensity and uniformity
All-in-one design (controller, emitter & power supply)
Quiet, low noise system
Optimization of application-specific frequency emissions by changing only the emitter
Intuitive user interface
Provides system status and troubleshooting
PLC activation and control
Control and monitor power levels, exposure times/routines, system health and safety lockout via PLC interface
The BlueWave® AX-550 V2.0 is a LED light-curing system that combines a controller, emitter, and power supply into a compact and quiet design. It combines high intensity with high uniformity and a large curing area to maximize light delivery. Eliminating the need for a large, traditional-style controller, this unit has a greatly reduced footprint and is easily integrated into Dymax conveyors and other machines or automated systems. The high-intensity emitters are detachable, and the system is field-upgradable so users can switch to another wavelength or upgrade to a more powerful emitter if desired. It is CE compliant for global installation and features programmable curing time and intensity settings. The flood cure system is best used for larger curing areas, yet the unit is compact and quiet.
This curing system also features an easy-to-navigate user interface with push-button controls. Units can be password protected to limit access to only authorized users and protect process parameters. The BlueWave® AX-550 V2.0 is warrantied against defects in material and workmanship for one year from the date of purchase.
PROPERTY |
Specification |
Output Frequency |
RediCure® – 365 nm |
|
PrimeCure® – 385 nm |
|
VisiCure® – 405 nm |
Intensity Output* at 25-mm Working Distance |
RediCure® – 650 mW/cm² |
|
PrimeCure® – 800 mW/cm² |
|
VisiCure® – 800 mW/cm² |
Operating Environment |
10°C to 40°C (50°F to 104°F) |
|
0-80% non-condensing |
|
2000-meter max. altitude |
Weight |
14.1 lbs. [6.4 kg] |
Dimensions (H x W x D) |
6.61 in x 11.45 in x 6.88 in [16.8 cm x 29.1 cm x 17.5 cm] |
Cooling |
Air cooled |
Unit Warranty |
1 year from purchase date |
Shipping & Storage Conditions |
Temperature: -20°C to +50°C |
|
Humidity 10-80% RH, Non-condensing |
