DYMAX 5000-EC Flood Lamp
Need assistance? Please click here to contact us~!! Click here
Concentrated 12.7 cm x 12.7 cm curing area
Rugged brushed-aluminum construction
Low-cost UV cures for bonded areas larger than 1/2 inch² or small batch processing
UV curing flood lamps can be conveyor mounted or used as stand-alone, bench-top systems
The Dymax 5000-EC Series UV curing flood lamps are designed for high-intensity, rapid UV curing of UV adhesives, UV coatings, and UV inks. 5000-EC UV curing lamps are designed for processes requiring higher-intensity UV light concentrated in a narrow 5 in x 5 in area. The 5000-EC series UV flood lamps deliver concentrated light primarily in the UV-A range (320-390 nm wavelength) to provide low-cost cures for bonded or coated areas larger than 1/2 inch2 or can be used for small batch processing or conveyor-mounted UV curing.
The faster curing capability of the 5000-EC UV flood lamp systems gives them the additional ability to cure UV conformal coatings. They are also used for a variety of UV bonding, UV potting, UV sealing, UV tacking, and UV encapsulating applications within the industrial, automotive, electronic, medical device, and optical industries.
The 5000-EC UV curing flood lamp consists of a power supply, reflector housing, and 400 Watt metal halide UV curing bulb. Accessories can be ordered with or retrofitted to the UV curing lamp after purchase, including shutter assemblies, UV shields, and UV flood lampstands. Complete UV flood systems are also available.
|
PROPERTY |
Specification |
|
Output Power |
400 Watts |
|
UV Light Source |
Unfiltered UVA flood |
|
Typical Intensity in the UVA range (320-390 nm)* |
225 mW/cm² |
|
Dimensions of Illuminated Area |
5 in x 5 in [12.7 cm x 12.7 cm] |
|
EC Input Power Requirements |
Universal 90-265 VAC (grounded), 47-63 Hz |
|
Power Supply Weight |
12.25 lbs. [5.6 kg] |
|
Power Supply Dimensions (approximate) |
12 in L x 16 in W x 4.25 in H [30.5 cm x 40.6 cm x 10.8 cm] |
|
Reflector Housing Dimensions (approximate) |
6.75 in L x 6.75 in W x 8 in H [17.2 cm x 17.2 cm x 20.3 cm] |
|
Reflector Housing Weight |
2.7 lbs [1.2 kg] |
|
Operating Environment |
10-40°C |
|
|
0-80% non-condensing |
*Product output intensity is measured by Dymax ACCU-CAL 50 radiometer at 3" distance
