DYMAX 2000-EC Flood Lamp

20.3 cm x 20.3 cm curing area
Rugged brushed-aluminum construction
Ideal for batch processing and the UV curing of large areas
UV curing flood lamps can be conveyor mounted or used as stand-alone, bench-top systems

The Dymax 2000-EC Series UV curing flood lamps are designed for general purpose, low-intensity curing of UV adhesives, coatings, and inks. A Dymax 2000-EC UV flood lamp is designed to effectively limit output energy to longwave (UVA), the worker-friendly portion of the spectrum. The 64-square-inch curing area of the 2000-EC Series UV floodlights makes them well suited for laboratory production and large-batch processing.

2000-EC UV curing lamps are used for a variety of UV bonding, UV potting, UV sealing, UV tacking, and UV encapsulating applications within the industrial, automotive, electronic, medical device, and optical industries.

The 2000-EC UV curing flood lamp consists of a power supply, reflector housing, and 400 Watt metal halide UV curing bulb. Accessories can be ordered with or retrofitted to the UV curing lamp after purchase, including shutter assemblies, UV shields, and UV flood lampstands. Complete UV flood systems are also available.

PROPERTY

Specification

Output Power

400 Watts

UV Light Source

Filtered UVA flood

Typical Intensity in the UVA range (320-390 nm)*

105 mW/cm²

Dimensions of Illuminated Area

8 in x 8 in [20.3 cm x 20.3 cm]

EC Input Power Requirements

Universal 90-265 VAC (grounded), 47-63 Hz

Power Supply Weight

12.25 lbs [5.6 kg]

Power Supply Dimensions (approximate)

12 in L x 16 in W x 4.25 in H [30.5 cm x 40.6 cm x 10.8 cm]

Reflector Housing Dimensions (approximate)

9 in L x 10.5 in W x 7.5 in H [22.9 cm x 26.7 cm x 19.1 cm]

Reflector Housing Weight

3.4 lbs [1.5 kg]

Operating Environment

10-40°C



0-80% non-condensing

*Product output intensity is measured by Dymax ACCU-CAL 50 radiometer at 3" distance
